Hydraulic pressure relief valve 20l/mn CP7/1V (15-155 bar)

Hydraulic pressure relief valve 20l/mn CP7/1V (15-155 bar)

CP71V

R930044850

> Technical sheet

Available

To see our prices and order, you must create an account or log in

Sign up or Log in
Pressure adjustment range15 - 155 bar
MaterialSteel
Flow Max20 l/mn
AssemblyIn line
ConnectionGaz - 1/4"
Adjustment typeBy handwheel
Operation typeDirect

Direct acting relief valve

This hydraulic pressure relief valve offered by OCGF have the function of limiting the pressure and providing protection to the pump in a hydraulic circuit. The operation type of this pressure relief valve is Direct.This pressure relief valve with reference CP71V has a pressure of 15 - 155 bar. It is adjusted By handwheel. The assembly is In line. It has a maximum flow capacity of 20 l/mn. For technical advice, do not hesitate to contact us using the contact details at the bottom of this page.
